Place of Origin	China
Brand Name	Dongfeng
Model Number	4x4 Desert Tourist Vehicle
Minimum Order Quantity	2 unit
Price	FCA (email reply based on different models)
Delivery Time	30-45 days
Payment Terms	T/T
Supply Ability	less than1000pcs/month (Orders must be made 30 days in advance if more than 1000)

Vehicle parameters	Overall length(mm)	9050
	Overall width(mm)	3250
	Overall Height(mm)	4150
	Wheelbase(mm)	6000
	Front/rear suspension(mm)	1050/1800
	Approach/departure angle(º)	39/36
	Ground clearance (front axle/rear axle)(mm)	450/450
	Operating speed (unloaded/fully loaded)(km/h)	30/30
	Track width(front/rear)(mm)	2530/2360
	Minimum turning radius (m)	10
	Maximum slope	10%
Engine parameters	Engine model	L375 30 MechanicL375 30, al pump diesel engine
	fuel	diesel
	最大功率(kw/r/min)	276KW

	最大扭矩(N.m/r/min)	1480N/m 1400r/min

	Displacement(L)	8.9
	Emission standard	National III
	Drive Type	4x4
Chassis parameters and configuration	Transmission	Fast 9JSD150T mechanical manual transmission
	Frame	Stamped riveted frame structure, front outer width 860mm, rear outer width 800mm, High strength beam specific steel plate.
	Maximum cross-sectional size of longitudinal beam	(Abdominal height x Wing width x Plate thickness) 280mm x 80mm x (8+6) mm
	Front Axle	Dajiang 7.5 ton integrated steering drive axle, with wheel reducer, automatic adjustment arm, and drum brake; Speed ratio: 5.921.
	Middle/Rear Axle	Dajiang 7.5 ton integrated drive axle, with wheel reducer, automatic adjustment arm, and drum brake; Speed ratio: 5.921.
	Suspension	Spiral spring suspension, two spiral springs, two shock absorbers, and four thrust rods
	Suspension	Spiral spring suspension, two spiral springs, two shock absorbers, and eight thrust rods
	Steering	Detached trapezoidal transformation mechanism with hydraulic assistance and a diameter of 480mm steering wheel
	Braking	Dual circuit pneumatic braking system, air brake, rear axle spring energy storage parking brake.
	Cooling system	Aluminum water tank with air and intercooler, with a diameter of 640mm fan
	Fuel supply system	The main fuel tank is 260L, with a maximum driving range of 500Km.
	Transfer case	HCF250 high and low speed, full-time drive, with axle differential lock, can be forcibly locked
	Wheels and tires	Four 28L-26 vacuum tires
	Electrical system	System power supply 24V, combination instrument
	electric generator	Integrated, 24V.165A
	Vehicle body	Integrated welding type, rated passenger capacity of 23 people (including driver), safety belt (JD-B021)
Vehicle design		Dongfeng Motor Company
OEM customization		Wuhan Junfeng Automobile Co., Ltd.

The King of the Desert-4x4 Desert Tourist Vehicle
